ZX6350C/D/A drilling and milling machine
Keyword:
ZX6350C/D/A drilling and milling machine
Telephone:13793702928
- Product Detail
- Feature
- Accessories
-
- Commodity name: ZX6350C/D/A drilling and milling machine
Machine tool use
The guide rail surface of the drilling and milling machine has been heat treated to have high hardness and strong steel. The gears are ground teeth and have been quenched and tempered by high frequency to have low noise and durability.
The electronic control part uses pure copper motors and national 3C certified products, which are safe, stable and have a long life.
Drilling and milling machines can be used for various forms of processing such as drilling, reaming, reaming, tapping and scraping end faces. They are widely used in
Mechanical processing in large, medium and small enterprises, townships and individual industries, and processing of small and medium-sized parts in various machine manufacturing industries. It is also suitable for repair workshops .
Machine parameters
model
ZX6350C
ZX6350D/A
Spindle taper
MT4 ( vertical ) 7:24 ISO40 ( horizontal )
7:24 ISO40
Spindle travel
120mm
120mm
Distance from spindle end face to worktable
80-460 mm
80-460 mm
Spindle speed range (rpm)
115-1750 ( standing ) 40-1300 ( sleeping )
90-2000( standing ) 40-1300( sleeping )
working desk size
1200*280 mm
1200*280 mm
Workbench travel (X/Y/Z)
700/260/400 mm
700/300/450 mm
Spindle travel
120mm
120mm
main motor power
1.5kw ( standing ) 2.2kw ( lying )
1.5kw ( standing ) 2.2kw ( lying )
(X/Y) axis motor power
0.75kW
0.75kW
(Z) axis motor power
0.75kW
0.75kW
Dimensions
1380*1580*2095 mm
1400*1400*2260 mm
weight
1200/1300
1250/1350kg
-
机床特点
可实现立、卧铣两种加工功能。
立式主轴套筒具有手动和微动两种进给。
X、Y、Z三方向导轨副超音频淬火后磨削。
X、Y、Z三向机动进给。
用途：本机床可用于金属材料和其他材料进行钻、铣、镗、攻丝等多种切削，广泛应用于单件或成批生产的仪表工业、机械制造、建筑装饰和修配行业。
-
序号
名称
数量
1
X向电子走刀器
1
2
数显
1
3
平口钳
1
4
铣夹头
1
5
组合压板
1
6
工具箱
1
7
拉杆
1
8
升降曲柄
1
9
手轮
1
10
进刀手柄
1
11
梅花扳手
1
12
开口扳手
1
13
说明书
1
14
塑料油壶
1
15
一字螺丝刀
1
16
十字螺丝刀
1
17
内六角扳手
1
Product Video
FAQ
Who are we?
We are located in Shandong, China and have been selling to the domestic market since 2014 (70.00%), Northern Europe (10.00%), Eastern Europe (10.00%), Africa (5.00%), the Middle East (3.00%), and South America (2.00%). Our office has a total of 51 to 100 people.
How do we ensure quality?
Always provide pre production samples before mass production; Always conduct final inspection before shipment;
What can you buy from us?
CNC turning and milling compound lathe, CNC lathe, CNC vertical machining center, CNC vertical milling machine, CNC vertical lathe, gantry machining center.
Why should you purchase from us instead of other suppliers?
We specialize in manufacturing these products for 20 years and have obtained ISO 9001 certification; Ce certification; EAC certification.
Do you have a physical factory?
Yes, we are a CNC lathe manufacturer from Tengzhou City, Shandong Province. We have a professional technical team, sales team, and after-sales team.
Can you customize the machine?
Yes, we integrate design and development together, with experienced engineers and assembly technicians.
What services can we provide?
Accept delivery terms: FOB, CFR, CIF, EXW; Accepting payment currency: USD, CNY; Accepting payment types: T/T, L/C, Western Union remittance; Language: English, Chinese
May I visit your factory?
Okay, we warmly welcome you.
