X6036 universal milling machine horizontal milling machine
Keyword:
X6036 universal milling machine horizontal milling machine
Telephone:13793702928
- Product Detail
- Feature
- Accessories
-
- Commodity name: X6036 universal milling machine horizontal milling machine
Machine tool use
A milling machine is a common metal cutting machine tool. The machine tool spindle taper hole is equipped with various cylindrical cutters, forming cutters, end mills, angle milling cutters and other cutting tools directly or through accessories.
Suitable for processing planes, bevels, grooves, holes, machinery manufacturing, molds, equipment, instruments, automobiles, and motorcycle industrial processing equipment of various parts.
Machine parameters
model
X6036A
X6036B
Spindle taper
7:24 ISO50
7:24 ISO50
Distance from spindle center line to cantilever beam plane mm
60-500
60-500
Distance from spindle end face to worktable mm
175
175
Spindle speed range r/min
60-1800（12stage）
60-1800（12stage）
Workbench size mm
1250×360
1500×360
Worktable travel (X/Y/Z) mm
600/320/360
1000/320/380
Work table vertical and horizontal feed mm/min
22-555 (8stage) (max.810)
15-370 (8stage) (max.540)
Feed amount up and down on the workbench mm/min
590
590
T-slot mm
3/18/80
3/18/80
Main motor power kW
4
4
Weight (kg)
2200/2400 _
2200/2400
size
1880×1700×1700
2220×1790×1700
-
机床特点
主轴刚性强，响应能力强。
响应表3 X，Y，Z方向操纵行驶，X 1000 mm。
响应X、Y、Z三方向导轨超音频淬火，精密研磨。
响应手动润滑装置对滚珠丝杠进行引导和润滑。
采用特殊配件可配置，铣头，铣削功能。 -
序号
名称
数量
1
X向电子走刀器
1
2
数显
1
3
平口钳
1
4
铣夹头
1
5
组合压板
1
6
工具箱
1
7
拉杆
1
8
升降曲柄
1
9
手轮
1
10
进刀手柄
1
11
梅花扳手
1
12
开口扳手
1
13
说明书
1
14
塑料油壶
1
15
一字螺丝刀
1
16
十字螺丝刀
1
17
内六角扳手
1
