- Commodity name: CK6160 Flat Bed CNC Lathe Independent Spindle Stepless Speed Control
1 Structural characteristics and functional requirements of machine tools
1.1 This series of machine tools is a mature product mainly exported by our company. The whole machine has a compact structure, beautiful appearance, large spindle torque, high rigidity, stable and reliable performance, and excellent accuracy retention.
1.2 The optimized design of the headstock is suitable for turning discs and shafts. It can process straight lines, arcs, metric threads, and multi-start threads. It is suitable for turning discs and shafts with complex shapes and high precision requirements. Parts Processing.
1.3 The machine tool guide rails and saddle guide rails are made of hard guide rails made of special materials. After high-frequency quenching, they are super hard and wear-resistant, durable and have good machining accuracy maintenance.
1.4 The CNC system adopts GSK980T C3 system , using domestic famous ball screws and high-precision screw bearings.
1.5 The spindle adopts a high-precision spindle bearing set and has been precision assembled and dynamically balanced tested to ensure high spindle accuracy, low noise and strong rigidity.
1.6 Each lubrication point uses a forced automatic lubrication device to lubricate the screw and guide rail at fixed points and quantitatively . When there is an abnormal state or insufficient oil, a warning signal is automatically generated.
1.7 adopts domestic three-jaw self-centering manual chuck as standard (hydraulic chuck is optional) .
1.8 The guide rail is equipped with a scraping device to prevent the guide rail from being corroded by iron filings and coolant, and facilitate the cleaning of iron filings.
2 CK6160 main technical parameters and configuration table
serial number
project
unit
parameter
CK6160 /1000/1500/2000/3000
1
Maximum rotation diameter of the bed
mm
Φ 600
2
X guide rail span
mm
210
3
Z guide rail span
mm
400
4
Maximum rotation diameter on the slide
mm
Φ 395
5
Needle distance
mm
1 000/1500/2000/3000
6
Maximum turning length
mm
850/1350/1850/2850
7
Center high
Distance from bed
mm
345
from the ground
mm
11 80
8
Spindle through hole diameter
mm
Φ82 optional Φ130
9
Bar diameter
mm
Φ 80 (128)
10
Equipped with hollow chuck tie rod through hole
mm
Φ65（Φ115）
11
Spindle end type
A 2-8(A2-11)
12
chuck
mm
Ordinary φ250 (φ 380)
13
Spindle taper hole taper
No
Metric 140 , 1:20
14
Spindle limit speed
rpm
1800
15
Tailstock sleeve diameter
mm
φ75
16
Tailstock sleeve inner hole taper
No
MT5 #
17
Tailstock sleeve travel
mm
150
18
Tailstock configuration
Ordinary hand crank
19
Number of knives in electric tool holder
Bundle
4 (optional 8-station electric tool holder )
20
Knife size
mm
□25×25(four stations)
twenty one
Lead screw model
X direction
mm
FD C 25 10 -P3
Z direction
mm
FD C4008 -P3
twenty two
X/Z rapid movement speed
m/min
6/8 _
twenty three
X-direction travel
mm
320
twenty four
Minimum setting unit
mm
0.001
25
main motor power
KW
7.5
26
Total power
KW
13
27
Machine tool net weight
Kg
2680/3050/3450/4250
28
Overall dimensions (length × width × height)
mm
2650/3150 /3650/4650 ×1 65 0×1 75 0
Machine tool accuracy standards
Test items
Standard tolerance ( mm )
Periodic axial movement of the spindle
0.005
Radial runout of spindle chuck positioning cone surface
0.005
Position accuracy
Repeat positioning accuracy A
±0.005
Diameter consistency
0.01/150
Flatness
0.0 25 /φ 3 00
Thread pitch product error
0.010/ 10 0
Surface roughness
Ra1.6μm
Main configuration list
name
Specifications and models
quantity
brand
Origin
Control System
Guangshu 980 TC3
1 set
Guangshu
Domestic
Spindle structure
Promise
1 set
self made
Domestic
Screw bearing
Special bearings for ball screws
1 set
Domestic
Spindle motor
7.5 KW servo
1 set
Guangshu
Domestic
guide
High frequency quenching
1 set
self made
Domestic
ball screw
2510/4008
1 set
north
Domestic
Knife holder
Four-station electric tool holder (optional 8-station )
1 set
Wenchang / Yaxing
Domestic
Automatic lubrication device
RBCLB-2BZK
1 set
He Jin
Domestic
Three-jaw manual chuck
K11250C (optional hydraulic)
1 set
Domestic
cooling pump
P=120W
1 set
Domestic
